This machine can automatic realize functions of bag- making, filling, sealing, printing, cutting, etc. The finished bag with square bottom and vertical side .Can be stand on the table with pretty shape .This packaging machine adopts import servo motor for film feed and the man-machine interface uses advanced touch screen. Operation simpler and more convenient .All of the components adopts international famous brand, PLC is SIEMENS, servo motor is PANASONIC, touch screen is SIEMENS, cylinder and air valve is SMC. parts which contact with material 、control cabinet 、main frame are made of stain less steel304
Τεχνικές παράμετροι:
Packing speed(MAX): 20-30 bags/min(depend on the weight from 250 gram-1000 gram)
Bag type: Square bottom bag (gusseted bag with square bottom )
Bag size: Front width: 80～190 mm; Side width: 25～60 mm Length: 100～380 mm
Compressed air consumption: 0.6 MPa 350 L/min
Electric requirement: 380V/5.5 kW 50 Hz
Features :
Film transport system and horizontal Jaw motion both drive by Panasonic motor
Safe quick change of tube and collar by just pull out the bracket
Η οπτοηλεκτρονική ανιχνεύει τη θέση του φιλμ στο κολάρο για να διορθώσει την εκδρομή ταινίας
Electrical photo sensor inducting color code to control bag length
Μοναδική δομή ασφάλισης φιλμ-τροχού για να αποφύγετε την παραμόρφωση της ταινίας
Ανεξάρτητη ρύθμιση θερμοκρασίας
Various types of heating sealable laminated films namely PE/BOPP, CPP/BOPP, CPP/PE PE/NYLON,
aluminum foil based can be run on the machine.
The packaging machine also can be used for Polyethylene Film Sealing by changing correspond equipment
